Folding filter Paper frame pre-filter air filter

FOB Reference Price:Get Latest Price
$10.00 - $50.00 / Piece | 10 Piece/Pieces (Min. Order)
Model Number:
JLAF5G
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
JielvFilter, Jielv Filter
Weight:
1-2KG
Certification:
ISO9001
Efficiency:
95%, G4(EN799)
Construction:
Panel Filter
Filtration Grade:
Pre Filter
Medium Material:
Other
Dimension(L*W*H):
Width X Height X Depth
Material:
Polyester synthetic fiber / cotton fiber blended nonwoven
Keyword:
Air filters
External Frame:
Heat-resistance waterproof paper frame
Inner frame:
Steel wire/ iron wire
After-sales Service Provided:
No overseas service provided
Warranty:
1 Year
Supply Ability
Supply Ability:
1000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
Bubble pack + wellpappe + stretch films + wood frame.
1.Packing with plastic
2.Packing with stretch film
3.The out packing with wood
Port
Guangzhou
Product Description
Product name
JLAF5G  Paper frame folding pre-filter
Material
High quality polyester synthetic fiber / cotton fiber blended nonwoven filter material
External Frame
Heat-resistance waterproof paper frame
Inner frame
Welded steel wire protection mesh / spray cast iron wire set mesh
Efficiency
G4(EN799): Gravimetric efficiency≥90%
Operating temperature
≤70℃
Humidity
≤100%RH
Recommended Max. Final Pressure
250Pa
Applications
Commercial and industrial, pre-filter air conditioning systems, stable performance. Clean room resh air conditioning system. Automobile industry. Hotels, office buildings.

Model
Dimension(mm)
Rated Air Flow
EN799
Color of filter material
No. of pleat

width
Height
depth
(m³/h&Pa)

JL-GZZ6646
595
595
46
1700/35   3400/50
G4
Dark green
15
JL-GZZ6636
290
595
46
850/35    1700/50
G4
Dark green
8
JL-GZZ6695
490
595
46
1400/35   2800/50
G4
Dark green
12
JL-GZZ6395
595
595
95
1700/35   3400/50
G4
Dark green
18
JL-GZZ6595
290
595
95
850/32   1700/50
G4
Dark green
8
JL-GZZ6646
490
595
95
1400/32   2800/50
G4
Dark green
12
JL-GZZ6346
290
595
46
850/35     1700/50
G4
Dark green
15
JL-GZZ5646
409
595
46
1400/35   2800/50
G4
Dark green
25

Product Advantage
Jielvfilter air Filters use high quality filter element to trap the airborne dust and dirt, including particles as small as a grain of sand and provide longer lasting engine protection.

1.High Quality Control air filter
2.Rapidly delivery
3.Sufficient capacity supply of air filter
4.Customer's Designs and Logos on air filter boxes are welcome
5.Favorable price of air filter
6.Vireaty of Designs are allowed
7.Small Order of air filter are Acceptable
8. air filter OEM Accepted

Application: commercial and industrial, pre-filter air conditioning systems, stable performance. Clean room fresh air conditioning system. Automobile industry. Hotels, office buildings.

About Jielvfilter

Guangzhou Jielv Environmental Protection Co., Ltd. is famous for high-tech filtration, separation and purification, committed to provide the highest quality filtration products to meet worldwide customers various needs with excellent service.

Main Products
We have been meeting global demand with our high quality products & best possible technical support to our End-user, OEM/ODM customers. Our main business covers from liquid filtration filters: PP Melt Blown Filter Cartridges, String Wound Filter Cartridges, Membrane Pleated Cartridges, Activated Carbon Filters, Filter Bags and Filter Housing etc.; and dust filtration air filter bags: PP, Polyester, Polyester Antistatic, Polyester Waterproof & Oil Repellent Antistatic, PPS, Aromatic Polyamideimide(P84), Acrylic, Nomex, Glass Fiber, FMS, PTFE needle felt air filter bags etc., which have been widely applied into fields of Process, Pharmaceutic, Desalination, Food & Beverage, Pool & Spa, Cement Plant, Coal Fired Boiler, Iron Works, Metallurgic Plant Gas and Liquid Filtration Industrial etc....

Main Market
On the basis of the powerful technical force, standard testing equipment, strict quality-controlled systems and the excellent after-sales services, we are striving for the more new and suitable products for the customers and the market. We won the trust and good remarks of a numbers of customers because of the high quality and reasonable price. We sale 40% filters in China mainland and export 60%, oversea main market are Southeast Asia, the Middle East, Africa, Europe and the USA etc..

Headquarter office in Guangzhou, China. JIELV Filter welcome your contacts.

Office

Team


Meeting room

Warehouse


Our Certifications
Contact Jielvfilter
Name
Shelly Lee
Phone/ WhatsApp
+86 150 1845 7132
Fax
86 20 3788 9066
Skype
shelly0258
Website
www.jielvfilter.com
Add
D Block, Kehui Park, Daguan Middle Road 95, Tianhe District Guangzhou City, China.
FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
